DTS 601

Reliable endurance runner with excellent sawing flexibility. The most cost-effective and extremely long-lasting solution for cutting medium-sized stones in building construction, paving and path construction.


The extremely robust DTS 601 table saw is created for professional, reliable and permanent construction site use. With a saw blade diameter of up to 650 mm (standard 500 mm) the diamond saw achieves a maximum cutting depth of 220 mm (standard 150 mm) and cutting lengths of up to 800 mm. The powerful 400 V motor with 3.6 kW achieves a working speed of 1,400 rpm, ideally sized for optimal cutting performance in the processing of medium-sized stones and masonry.

The durable table saw proves its strengths in demanding applications in building construction as well as in pavement and path construction. Thanks to its swivelling cutting head, the stone saw is a master in making precise chop cuts. The rubberized saw table guarantees non-slip separating cuts. The integrated water spray system ensures optimal saw blade cooling and the immediate removal of dust. The system works extremely efficiently with minimum water consumption and meets current safety standards.

The high-quality, low-maintenance, welded steel construction with a precision table support results in perfectly fitting cuts - for the life of the machine. The smooth-running cutting table includes an adjustable angle stop. The standard wheelset makes it easier to move the table saw on the construction site and when loading it into a vehicle. The saw’s foldable table legs make the machine compact, helpful for quick and easy transport. Handles are welded to the front and rear of the saw to aid transportation. The reliable endurance runner is recommended with the best practicality and for universal use. Read more about the table saw DTS 601:

DTS 601 Tischsäge Tischtrennsäge Trennsäge Steinsäge mit Dia
DTS 601 Tischsäge Tischtrennsäge Trennsäge Steinsäge Rückseite mit Dia
DTS 601 Tischsäge Tischtrennsäge Trennsäge Steinsäge Wasserwanne
DTS 601 Tischsäge Tischtrennsäge Trennsäge Steinsäge Maschinenfüße
DTS 601 Tischsäge Tischtrennsäge Trennsäge Steinsäge eingeklappt
Technical data
DTS 601
cutting depth standard
150 mm
cutting depth max.
220 mm
cutting length
800 mm
saw blade Ø standard
500 mm
saw blade Ø max.
650 mm
arbor size
25.4 mm
motor output
3.6 kW / 400 V
saw blade speed
1400 1/min
dimensions (L/W/H)
1380/680/1650 mm
weight
129 kg
Further information
  • The water spraying system ensures optimum saw blade cooling and the immediate removal of the sawing debris with the lowest water consumption and also complies with the current safety Standard
  • Table saw with swivelling cutting head
  • High-quality, low-maintenance construction
  • Welded steel construction and plastic water basin with precise table support for accurate cuts
  • The adjustable saw head also allows chop cuts
  • Foldable legs for fast and compact Transport
  • Standard wheelset makes it easier to move on site and to load into a vehicle
  • Roller table equipped with safety catch and locking mechanism
  • Integrated water pump transport lock
  • Removable splash guard
  • Rear sloping and removable water pan
  • Rubberised saw table for non-slip cuts
  • Best transport option by using (back/front) handles
  • Smooth cutting table with adjustable angle stop
  • Hinged saw blade guard for easier exchange of saw blades
  • ON / OFF switch with EMERGENCY STOPuser-friendly in a protected position
